75kva Three Phase Pad Mounted Transformer Step Down 4160V To 208V 120V Electrical Power Transformers

WINLEY's three-phase pad mounted transformers are widely supplied to the North American market, especially the United States. We are committed to providing high-quality, reliable, and efficient power distribution solutions to meet our customers' needs.

A padmount or pad-mounted transformer is a ground mounted electric power distribution transformer in a locked steel cabinet mounted on a concrete pad. Since all energized connection points are securely enclosed in a grounded metal housing, a padmount transformer can be installed in places that do not have room for a fenced enclosure.

Technical drawings

Feature

• 60 Hz operation.
• 65°C average winding rise.
• Loop feed arrangements.
• Dead and live front type of HV terminals.
• HV BIL 60 kV (Dead Front).
• LV BIL 30kV.
• Three-point latching of low-voltage door.
• Rigid steel partition.
• Transformer tank welded from cover to base.
• Permanent nameplate.
• One-inch NPT pipe cap filling provision.
• ANSI tank ground pads.
• One-inch drain valve and sampler.
• Automatic pressure-relief valve (35 SCFM).
• Tap changer with (± 2.5%)
• Painted olive-green color (Munsell 7GY 3.29/1.5).
• Designed, manufactured and tested in accordance with the latest ANSI/IEEE standards.
